Floor Swing Door Operator
SWING GATE OPERATORS

Floor Swing Door Operator

This floor swing door operator installs completely below floor level — no arm, no rail, no visible hardware above the surface. Handles gates up to 250 kg. Bluetooth and 4G built in. Obstacle rebound, waterproof housing, and interchangeable shaft heads for any market. Ships complete as a kit.

250 kg
Max gate weight
56 Nm
Output torque
≤60 dB
Running noise
Below floor
Concealed Install
Request a Quote Call: +86 198 7941 5670
✓ Free Site Survey
✓ Certified Installation
✓ Local Warranty

Overview

Open Bear's floor swing door operator installs completely below floor level — no arm, no rail, no visible hardware above the surface. Handles gates up to 250 kg and 1.2 m wide on a 24V DC motor. Bluetooth and 4G built in. Obstacle rebound, waterproof housing, and interchangeable shaft heads for any market. Ships complete as a kit — nothing to source separately.

Bi-directional 90° opening and automatic positioning
Adjustable hold-open time (1-20s), opening & closing speeds
Active safety support for safety lights/curtains
Overview Image

Waterproof. Burst Proof. Anti-Corrosion. Built for What's Under Your Floor.

A floor-mounted operator faces conditions no wall-mounted unit does — water ingress, ground pressure, and corrosion from below. Rain, dust, and soil contact won't reach the motor — the housing is waterproof, burst proof, and anti-corrosion rated. Anti-CO protection prevents carbon monoxide build-up in enclosed or basement installations. Integrated die casting seals the body completely, preventing oil leakage. Closing speed adjusts independently via the speed control screw — set once during installation, holds through every cycle after that.

Waterproof housing — water and dust resistant
Anti-corrosion (antiseptic)
±5 mm body position adjustment
Waterproof Details

Bluetooth and 4G Built In. Open Your Gate from Anywhere.

Open your gate from your phone the day it is installed — Bluetooth and 4G are built directly into the unit, with no extra module to source or fit. Remote commissioning means your installer can adjust every parameter without crouching at the gate — all settings are reachable from a phone. Five access methods connect through the same controller from day one.

Bluetooth built in
Obstacle rebound - gate auto-reverses if blocked mid-swing
Remote commissioning — adjust parameters from phone
Connectivity Details

The Gate Opens. Nothing Else Shows.

Nothing shows once the job is done. The entire mechanism — motor, drive, and stainless steel shaft head — sits inside a recessed housing below the pivot point of the gate. No visible arm, rail, or motor from any angle after commissioning. A single unit opens one leaf to 90°. Fit two and they drive a double gate to 180° total — the cleanest installation finish in the Open Bear swing range.

No arm, rail, or bracket visible above surface
Single gate: 90° opening
Stainless steel shaft head
Concealed Details

Technical Specifications

Download Product Manual
Performance & Operations
Working voltage
220VAC ±15% / 50Hz
Motor operating voltage
24V DC
Power of motor
48W
Rated output torque
56 Nm
Angular speed
48°/s
Maximum opening angle
±90° (single) / 180° (dual gate)
Maximum door leaf length
1.2 m (single door)
